Low Hydrogen Electrodes - (7016)

Home » Products » Low Hydrogen Electrodes » Low Hydrogen Electrodes - (7016)

IDENTIFICATION :Printed on ElectrodeCLASSIFICATION:S:814-04: EB 5326 H2XAWS/SFA (5.1): E 7016APPROVALS: B.I.S., R.D.S.O. Class A3/B1CHARACTERISTICS:A basic heavy coated hydrogen controlled Radiographic electrode for welding of mild steel, Medium high tensile steel and low alloy steel suitable for steels of unknown composition and for non- machinable deposit on cast iron.APPLICATION:Sundeep 7016 is ideal for: Boilers, Pressure Vessels, Railway, Class III steel, Overhead Cranes, Oil Tanks, Heavy Structures, Ships, Earth moving equipments & for depositing buffer layer before hard-facing.CHEMICAL PROPERTIES :Carbon - 0.10% Max.Manganese - 0.80 – 1.40%Silicon - 0.36 – 0.60%Sulphur - 0.03% Max.Phosphors - 0.03% Max. TYPICAL MECHANICAL PROPERTIES OF ALL WELD METAL:Ultimate T. Strength - 520 – 610 N/mm2Yield Strength - 400 N/mm2 Elongation (L=5d) - 26% Reduction in Area - 60 – 75%Impact Value - 200C - 60 - 90 Joules CURRENT CONDITION :- AC/DC (+)
